2020年8月25日by 吴川斌243 Comments

Mentor PADS 相关软件资源下载分享

Mentor PADS 桌面自动化设计解决方案提供了简单易用的环境,可帮助您化解日常遇到的 PCB 设计挑战。利用 PADS, 您不仅可以更快、更好地完成工作,而且还能节省成本。

目前，新版本的Mentor PADS 分为：PADS Standard、PADS Standard Plus 及 PADS Professional 版本。

其中，PADS Standard、PADS Standard Plus与传统的PADS的体验是一致的，就是你之前用的老版本的pads，如pads 9.5，可以直接的转换的PADS Standard、PADS Standard Plus。而 PADS Professional 是其Mentor高端产品线Xpedition的功能简化版，跟传统的pads有很大的区别。

PADS Standard Plus 比PADS Standard支持更多的高级特性，面向需要设计流程更为完善且包含高级工具集的独立工程师,其中配备了增强的 Layout 和集成式分析与验证,可全面满足在快速创建高质量 PCB 时的一切需求。

PADS Professional 是 PADS 最高阶的套装,适合需要处理一切的工程师。

包括：

  • 处理最复杂的挑战，更好更快
  • 使用Xpedition技术提供了无可比拟的性能及超值的价格
  • 增加跨越PCB设计和FPGA协同设计效率
  • 使用HyperLynx提供信号/电源完整性和热分析和验证设计
  • 功能强大且易于使用的功能，包括集成射频，草图布线和真正的3D设计

这里，老wu特地汇总了Mentor 相关EDA设计软件资源（包括Mentor PADS 9.5及后续的最新版本并且会一直持续更新，敬请关注）分享给大家。

可提供下载的Mentor EDA软件资源包括：

  • Mentor PADS  (汇总了多个版本，包括最新版)
  • Mentor Hyerlynx (汇总了多个版本，包括最新版)
  • Mentor Xpedition (汇总了多个版本，包括最新版)

大家按需选择下载对应的版本，再次声明，Mentor PADS到了VX系列后，Standard版本跟Professional有很大的不同，Standard是传统的PADS版本升级，而Professional版本是Xpedition的功能简化版，他们的使用体验是不一样的。

同时，老wu提供了专用的Mentor PADS一键破解软件给大家：馒头破戒大师，针对mentor系列的软件都是适用的，包括pads、Xpedition、hyperlynx、npi等等。馒头破戒大师下载地址：http://mentor.mr-wu.cn

关于 Mentor PADS 的安装和破解教程

老wu之前写过pads各个版本的安装教程，大家可以在博客里搜索关键字“pads 安装”，在博客首页或者右侧的工具栏都有搜索输入框，输入关键字搜索即可收到pads的安装教程。





如何下载Mentor PADS PCB 设计软件合集

关注老wu博客的公众号，并在公众号里发送对应的下载关键字获取下载链接

关注吴川斌的博客公众号

在公众号里给老吴发消息:

下载|Mentor PADS

或者

下载|6012

建议复制粘贴过去不会码错字哟，O(∩_∩)O~
